Pretty surreal, right?įor 3 months over summer, I had the pleasure of working with an amazing team at Manson Construction Co. This allows you to transfer the entire plotting sheet (with borders and labels!) into your CAD/GIS package.Imagine a job where your office window looks out on a pod of dolphins surfing the bow wave of a giant container ship. You can plot X-Y grids (or tics), local projection lat-long grids (or tics) and WGS-84 lat-long grids.Īnother BIG feature of HYPLOT is the ability to send the plots out to a DXF file. HYPLOT has several border and title block options, including the national borders used by USACE, China and Russia.
This allows you to create stunning plots with your background files, such as ortho-photos (TIF), engineering plans (DXF/DGN), electronic charts (ENCs, ARCS), superimposed with your hydrographic survey data.
All of the background files that can be displayed in HYPACK® can also be printed/plotted in HYPLOT.
#CROSS SECTIONS IN HYPACK PDF#
HYPACK®’s plotting program (HYPLOT) allows you to send any combination of data files to your plotter or printer or to a PDF file. Luciano Fonseca of UNH-CCOM and provides advanced mosaicking and bottom classification routines. In HYPACK® Version 2008, the GEOCODER™ program was integrated as a standard side scan processing tool. The Target Book is in Rich Text Format and can be e-mailed and reviewed by clients or home offices in Microsoft Word®. Target measurement tools can be used to capture a GeoTIF image of each target, make measurements of its length, width and height, and save it to a Target Book. Targeting can be performed in real time, or in post-processing in the SIDE SCAN MOSAIC program. It can also handle XTF files from several side scan manufacturers own logging software. HYPACK®’s side scan processing routines accepts input from side scan or from the pseudo-side scan available from many multibeam systems. The SIDE SCAN SURVEY program supports analog and digital side scans, including some of the latest dual frequency and high resolution side scans.
#CROSS SECTIONS IN HYPACK SOFTWARE#
HYPACK® is the only hydrographic software package that offers side scan collection, mosaicking and targeting as a standard part of our package. Survey versus Survey volumes: Computes the volume quantity between two different surveys of an area. Reservoir volumes: Computes the volume and surface area of a reservoir at user-defined water levels.Ĭhannel volumes: Computes the volume quantities of the TIN surface versus a set of planned lines and their channel design templates.ĪDVANCED CHANNEL DESIGN volumes: Computes volume quantities of the TIN surface versus a complex area created in ADVANCED CHANNEL DESIGN. Input data can be from single beam, multibeam or multiple transducer surveys. The TIN MODEL program of HYPACK® can be used to compute several types of volume quantities. The latest capability added is support of beach volumes for beach replenishment projects. CROSS SECTION AND VOLUMES can read hundreds of sections, compute the volumes and send all of the sections to the printer/plotter in a matter of seconds. Over 20 methods are available to compute the area and volume of material for each profile segment (left slope, main channel, right slope), it can compute quantities for a single survey versus the design template, or for a pre-dredge versus an after-dredge comparison. The program is the de facto standard for volume computations by several national survey agencies. The CROSS SECTIONS AND VOLUMES program quickly computes volume quantities for cross sectional profile lines compared to the channel design template and channel overdepth template for each line. It can compute volume quantities either from sections across channels or from surface models (TIN MODEL). HYPACK® ability to compute volume quantities is unsurpassed. MAPPER: A binning routine that can select minimum, maximum, average, closest to cell center to represent each cell. SOUNDING SELECTION: Selects min/max soundings and fills in between. SORT: Selects the shoalest soundings and prevents overwritesĬROSS SORT: Selects random soundings and packs them in tight. There are several options for sounding reduction, depending on your final product.
